03 February 2019

Separated at birth?

Glasgow City Council has published the design for a new bridge across the River Clyde connecting Govan and Partick, next to the Riverside Museum. The bridge is to be 110m long, with an opening span of 63m, and a swing bridge has been chosen so that the bridge can operate in high winds.

The bridge has been designed by CH2M Hill (now part of Jacobs), who in their previous incarnation Halcrow have previously delivered quite a few Clyde crossings. It's expected that a planning application will be made this summer, with the intention to complete construction in 2021.

The budget has been previously stated as £10m, but I don't know if that's accurate.

So ... spot the difference.



The top picture is the new Govan-Partick bridge. I'm sure any similarity to the Puente de la Mujer in Buenos Aires, shown in the second picture, is entirely coincidental.

I was especially amused to see that the artist tasked with visualising Glasgow's new design adhered so slavishly to their brief (presumably "copy this one please, pal") that they even included a sailing ship.

Or maybe this was their source material:


That one, of course, is in Dublin, and does at least have some back-stays unlike the Buenos Aires span or its Glaswegian clone. What is it about these bridges and sailing ships, anyway?

I don't think there's anything else I really want to say about the Govan-Partick bridge right now, so here are some more visualisations, and a rendered video:



02 February 2019

Bridge competition debris part 28: Upper Orwell Crossing

In the wake of the decision to cancel the Upper Orwell Crossing project, I realised that I've never taken the opportunity to feature the losing designs in the original design competition.

All these images are taken from an article in the Architects' Journal, as only William Matthews Associates have shared details of their design on their own website.

My conclusion on looking back through these is that the Foster and Partners designs were pretty well-deserved winners. It would be interesting to see how the project budget would have turned out had some of these submissions been chosen!

I've provided further comments below where appropriate.

Adamson Associates with William Matthews Associates and Ney and Partners








These are my favourites of the losing designs - they have a real sense of style even if it's accompanied by a huge slice of impracticality.

The first of two alternative designs for the main river crossing is an unusual cable-stayed bridge, with an inverted-V tower straddling the carriageway, and supporting the two approach decks. It is a bit like two Alamillo Bridges placed back-to-back. It has the effect that the central twin bascule span appears inconsequential compared to the approaches, which I find a little disconcerting. It also feels somewhat out-of-proportion to the site - possibly something more appropriate in a larger city.

The second alternative for the main river crossing consists of a series of huge box-girder structures, like inverted pyramids, supporting a twin bascule arrangement in the middle. This feels less odd in its relationship to the river, but also overpowered by formalism. At first sight the river supports look unstable, but if there's enough weight in the system and it's well enough held down by approach spans, it is in theory stable.

The design for the shorter opening span is conventional in form (a Dutch drawbridge, with the deck suspended from overhead booms), but with a visually attractive box form for the upper boom. Again, the design does not look very stable.

Knight Architects


It's difficult to judge the Knight Architects design based only on these two images. The structure illustrated appears to be a vertical lift span, with a single tower at each end rather than the more normal pair of towers. It's not clear where the counterweights would be, and the towers don't look substantial enough to deal with any overturning loads due to wind on the raised bridge deck.

The notable feature of the design is the presence of people on the bridge while it is lifted, as much a fairground ride as a bridge in this situation. It isn't normal to permit people on a moving bridge deck while it's in operation (the Scale Lane Bridge in Hull is an exception), but it's entirely feasible. It means the bridge can't be perfectly counterweighted, but that's true of many moveable bridges today anyway.

Marc Mimram



I think there's some head-scratching required to work out what is going on with the main Mimram design here. The highway bridge deck is supported from a forest of poles, and I think the central deck sections are lifted using draw-cables, pivoting on struts below so that they don't tilt. It's somewhere between a bascule drawbridge and a lift bridge. I don't like the look of it.

The second span is supported from two arch ribs tilted at different angles to give the impression of a ladder or railway track twisting through space. It's not a straightforward design and would require foundations at a scale disproportionate to what is actually merited. To add to the fairground feel of the contest, it reminds me of a rollercoaster track.

Wilkinson Eyre with FHECOR and Eadon Consulting








Wilkinson Eyre and their partners offered two variants on the same theme for the main crossing, both with twin bascules. One has two rectangular bascule leafs with a minimal counterweight. The other uses diamond shaped leafs, in an interesting arrangement which allows the rear part of the deck to act as a counterweight. I think the axle or pivots supporting these decks would be working very hard.

The design is obviously reminiscent of the same designer's bridge at Poole Harbour, the Twin Sails Bridge. That has had a history of problems, with the bridge closed in 2012 (soon after completion), and again in December 2018. Movable bridges can be troublesome at the best of times, and adding complexity to the more normal geometry may not be the best decision.
